Hikvision DS-7604NXI-K1/4P 4-Channel 4-PoE AcuSense VPro NVR
4-channel AcuSense VPro NVR with four PoE ports, 40 Mbps incoming bandwidth, 4K output, and one HDD bay supporting up to 10 TB.
A compact 4-channel Hikvision VPro network video recorder with four built-in PoE ports for direct camera connection, AcuSense deep-learning analytics, 4K video output, and support for one high-capacity surveillance hard drive.
Product Overview
The Hikvision DS-7604NXI-K1/4P VPro is a comprehensive 4-Channel NVR featuring four built-in Power-over-Ethernet (PoE) ports for direct plug-and-play IP camera installation. Powered by AcuSense deep learning analytics, the NVR provides advanced human and vehicle classification, significantly reducing unnecessary motion alerts and enabling quick, target-specific searches. It supports ultra-high-definition recording up to 12 MP and offers H.265+ smart compression to reduce storage requirements. Outfitted with independent HDMI (up to 4K) and VGA outputs, and supporting one SATA HDD up to 10 TB, this NVR is the ultimate all-in-one recording solution for hassle-free, professional-grade monitoring.
Why Buy This Product
4-Channel Plug-and-Play
Supports up to 4 IP cameras, offering a centralized local server with high-bandwidth 24/7 security recording.
4 Built-In PoE Ports
Features 4 independent Power-over-Ethernet (PoE) ports to power and stream video from cameras over a single network cable, eliminating complex power grids.
Deep Learning AcuSense
Equipped with smart AcuSense analytics to filter alarms and target human shapes and vehicles across all channels.
Direct 4K Surveillance
Displays crystal-clear video on direct displays via a 4K HDMI connection and independent VGA output.
Best for These Applications
DIY Installations
Perfect for quick, painless setups where you want to run one cable per camera straight back to the NVR.
Premium Smart Homes
Ideal for homeowners seeking a professional-grade security system with easy cabling and mobile app access.
Boutiques & Micro Retail
Excellent for small retail shops needing 2 to 4 high-definition cameras with local audio and video storage.
Dedicated Security Desks
Enables direct monitoring on a local 4K screen with zero network configuration for the monitor.
Key Advantages
- Integrated Power Supply: The built-in PoE power supply supports up to 36W total PoE power budget, enough to power 4 standard IP cameras.
- 12MP Recording Support: Captures the finest details by supporting recording resolutions up to 12 Megapixels.
- Efficient H.265+ Compression: Compresses video dynamically, reducing network bandwidth demands and saving up to 75% storage space.
- One-Click Search: Allows security staff to locate human or vehicle events with a single click, saving hours of manual scrubbing.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 1 |
| Shipping Weight | 1.9 |
| Image Count | 5 |
| Channels | 4 |
| Poe Ports | 4 |
| Hdd Bays | 1 |
| Max Storage T B | 10 |
| Decoding Capability | Up to 1-ch@12 MP, 2-ch@8 MP, 4-ch@4 MP, or 8-ch@1080p |
| Throughput Mbps | 40 |
| Power Source | 48 VDC, 1.35 A |
| Operating Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
Based on 15 customer reviews
PoE ports make installation a breeze
Plugged my Hikvision cameras directly into the NVR PoE ports and they auto-configured instantly. True plug-and-play.
Excellent choice for home security
Perfect capacity for a small house setup. The 4 PoE ports provide power to all cameras. AcuSense handles notifications beautifully.
Solid performance, setup took some time
Very well-built NVR. Took some time to set up remote access through Hik-Connect, but once configured, it has been solid.
Highly recommend PoE model
Definitely worth getting this version over the standard one to avoid needing a separate PoE switch. Power delivery is stable and silent.
