5MP (2592 × 1944) | Optical Zoom PTZ | 150m IR Night Vision | True WDR (120dB) | IP66 | Two-Way Audio | IK10 Vandal-Proof
The Matrix SATATYA PTZ5040P delivers continuous 360° pan and tilt coverage engineered for expansive commercial perimeters, rail hubs, and transit yards. Powered by 5MP Ultra HD imaging and a high-reach Optical Zoom PTZ, it illuminates up to 150m in complete darkness while supporting active target tracking.
Product Overview
The Matrix 5MP Ultra HD IR Dome PTZ Camera is purpose-built for mission-critical security applications where expansive coverage and rapid response are paramount. Featuring a high-performance 1/2.7" Progressive Scan CMOS Sensor, the camera produces crisp 2592 × 1944 resolution footage with exceptional low-light sensitivity. The optical zoom lens (Optical Zoom PTZ) combines with 360° endless rotation and rapid pan-tilt presets to track intruders, verify vehicle license plates, and investigate incidents across wide yards from substantial standoff distances.\n\nFor around-the-clock reliability, intelligent infrared LEDs illuminate dark perimeters up to 150m, while True WDR (120dB) counteracts extreme contrast caused by vehicle headlights or bright floodlighting. Built-in smart video analytics deliver automated alerts for motion, intrusion, and tripwire events. Smart H.265 compression cuts enterprise bandwidth and storage overhead by up to 50%, while two-way audio support enables security teams to challenge unauthorized personnel remotely in real time.
Why Buy This Product
Immense Optical Zoom PTZ Reach
Provides optical zoom reach up to 150m to identify vehicle plates, suspicious individuals, and perimeter breaches without image pixelation.
360° Endless High-Speed Tracking
High-velocity motorized pan-tilt mechanism sweeps expansive perimeters with automated guard tours and intelligent motion tracking.
Active Two-Way Audio Intercom
Allows central command operators to hear live audio and broadcast direct verbal warnings to deter trespassers before incidents escalate.
Best for These Applications
Logistics & Freight Depots
Monitoring expansive container yards, loading lanes, and perimeter fencing with long-distance optical zoom.
Large Public Venues & Plazas
Rapidly directing attention to crowd disturbances or emergency situations across wide concourses.
Airports & Transport Hubs
Tracking aircraft aprons, runways, and open transit concourses with high-speed automated preset tours.
Key Advantages
- High-Efficiency Progressive CMOS:Delivers sharp image clarity with high signal-to-noise ratio (>70dB) and fluid frame rates for fast-moving targets.
- True WDR (120dB) Dual-Exposure:Combines short and long exposure frames in real-time to preserve highlight details and shadow visibility simultaneously.
- Smart H.265 Video Compression:Optimizes video bitrates by up to 50% compared to legacy codecs, drastically reducing NVR storage costs and network bandwidth load.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 5.1 |
| Shipping Weight | 5.199999999999999 |
| Image Sensor | 1/2.7" Progressive Scan CMOS Sensor |
| Max Resolution | 2592 × 1944 |
| Min Illumination | Color: 0.01 Lux @ F1.2 (AGC ON), Monochrome: 0 Lux with IR |
| Lens Type | Motorized Optical Zoom |
| Focal Length And Fov | Motorized Optical Zoom, Autofocus Lens |
| Aperture | F1.6 - F4.4 |
| Supplement Light Range | Up to 150m |
| Supplement Light Type | IR |
| Ir Wavelength | 850nm |
| Video Compression | H.265, H.264, MJPEG |
| Video Bit Rate | 128 kbps - 8 Mbps |
| Audio Compression | G.726, G.711µ |
| Built In Microphone | Yes |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, IGMP, 802.1x, QoS, IPv4, IPv6, SSL/TLS, ONVIF Profile S/G/T |
| Wdr | True WDR (120dB) |
| Snr | >70dB |
| Image Enhancement | 3D DNR, BLC, HLC, Region of Interest (ROI), Day/Night Settings |
| Ethernet Interface | 10Base-T/100Base-TX Ethernet (RJ-45) with PoE support |
| On Board Storage | MicroSD Card slot, Up to 512GB |
| Smart Event | Motion Detection, Intrusion Detection, Tripwire Detection, Camera Tampering, Region Entrance, Region Exiting |
| Face Capture | No |
| Power | 12V DC ± 10%, PoE (IEEE 802.3af Class 3), Maximum 9W |
| Material | Metal Enclosure |
| Dimensions | Φ206.6mm x 329mm(Diameter x Height) |
| Weight | 5.1kg |
| Operating Conditions | Temperature: -30°C to 60°C, Humidity: Less than 95% RH (non-condensing) |
| Protection Rating | IP66 |
| Vandal Proof Rating | IK10 |
| Stock | 7 |
