VISIONPRO 412, Telecom, PBX, Matrix Comsec, 4 CO Lines, 12 Extensions, SOHO Analog PBX
High-density SOHO analog PBX system equipped with 4 CO trunk lines and 12 analog extensions, ideal for small hotels, clinics, and professional offices.
Product Overview
The Matrix VISIONPRO 412 represents the flagship model in the VISIONPRO SOHO PBX series, offering maximum analog line capacity with 4 PSTN trunk lines and 12 extension ports. Engineered for small hotels, medical centers, multi-department offices, and service centers, it provides a comprehensive voice management platform without requiring IT networking infrastructure. Featuring dual-channel auto-attendant capabilities, the VISIONPRO 412 can greet and guide two incoming callers simultaneously. It includes advanced analog telephony features such as call transfer, call pickup, barge-in, 3-party conferencing, flexible extension numbering, and dual power-fail emergency line bypass mapping.
Why Buy This Product
Maximum 4x12 Analog Capacity
Supports 4 PSTN lines and 12 extensions, providing maximum analog density in the VISIONPRO family.
Dual-Channel IVR Auto-Attendant
Answers 2 incoming trunk calls simultaneously to prevent caller busy signals during peak hours.
Dual Power-Fail Pass-Through
Maintains 2 active PSTN trunk lines mapped directly to extension phones during blackout events.
Best for These Applications
Small Hotels & Motels
Provides up to 12 guest room and staff desk phones linked to 4 incoming trunk lines.
Polyclinics & Centers
Medical facilities requiring multi-channel call answering and intercom across 12 desks.
Branch Office Outlets
Offices needing 12 desk extensions with toll restriction and call duration limits.
Key Advantages
- Simultaneous 2-Channel Auto-Attendant: Ensures callers never hit a busy tone even when multiple lines ring at the exact same time.
- Dual Power-Fail Ports: Maintains 2 active PSTN trunk lines mapped directly to extension phones during blackout events.
- Flexible Call Distribution: Configure incoming call ringing patterns (round-robin, simultaneous, or priority sequence).
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 1.4 |
| Shipping Weight | 1.7 |
| User Capacity | 12 |
| Max Ip Users | 0 |
| Analog Extensions | 12 |
| Digital Extensions | 0 |
| Co Lines | 4 |
| Sip Trunks | 0 |
| Ip Trunks | 0 |
| Gsm Channels | 0 |
| Pri Ports | 0 |
| Expansion Slots | 0 |
| Voip Channels | 0 |
| Voicemail Channels | 2 |
| Voicemail Storage | Dual-Channel Auto-Attendant Greeting Engine |
| Audio Conferencing | Dual 3-Party Audio Conferences |
| Call Detail Records | N/A |
| System Architecture | High-Density SOHO Analog PBX System |
| Power Supply | 24V DC, 1.0A via 100-240V AC External Adapter |
| Power Consumption | 18W Max |
| Mounting Form Factor | Compact Wall-Mount Chassis |
| Dimensions | 243 x 172 x 54 mm |
| Weight | 1.4 kg |
| Operating Temperature | 0°C to 45°C |
| Ethernet Interfaces | N/A |
| Voip Protocols | |
| Audio Codecs | DTMF, FSK |
| Certifications | CE, TEC, RoHS |
