The Matrix COSEC PANEL200P is an enterprise site controller panel managing up to 255 door controllers and readers. Powered by a Cortex processor and embedded Linux OS, it supports 25,000 users and a 500,000 event log buffer.
Product Overview
The Matrix COSEC PANEL200P serves as the central brain for enterprise access control architectures. It coordinates up to 255 door controllers and peripheral readers across large facilities, orchestrating global anti-passback, inter-panel interlocking, and centralized event logging. Equipped with dual Ethernet ports, RS-485 communication, USB expansion, and an embedded Linux operating system on a Cortex A8 CPU, the PANEL200P guarantees real-time synchronization between local door hardware and enterprise COSEC CENTRA/VYOM software.
Why Buy This Product
255 Device Capacity
Manages up to 255 door controllers and biometric readers from a single panel.
Global Anti-Passback
Enforces strict room-to-room entry and exit verification across complex facilities.
Dual Ethernet Ports
Provides redundant network pathways for high-availability enterprise IT networks.
Best for These Applications
Multi-Story Headquarters
Coordinates hundreds of access doors across complex commercial office towers.
Manufacturing Plants
Executes complex door interlocking and hazard zone access rules in real time.
High-Security Data Centers
Enforces multi-factor authentication and global anti-passback across server halls.
Key Advantages
- Centralized Intelligence: Decouples door logic from central servers so access decisions occur instantaneously.
- 500K Log Event Buffer: Retains complete security records even during primary network link outages.
- Linux OS Stability: Built on embedded Linux for 24/7 industrial uptime and cyber resilience.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 0.45 |
| Shipping Weight | 0.65 |
| User Capacity | 25000 |
| Log Capacity | 500000 |
| Event Buffer | 500000 |
| Doors Supported | 255 |
| Readers Supported | 255 |
| Cpu | Cortex A8 800 MHz |
| Operating System | Embedded Linux |
| Communication Interfaces | Dual Ethernet, RS-485, USB |
| Power Requirements | 12V DC @ 2A |
| Operating Temp | -10°C to +50°C |
| Operating Humidity | 5% to 95% RH Non-Condensing |
| Certifications | CE, FCC, RoHS |
