SETU VFX808, Telecom, Gateway, Matrix Comsec, 8 FXS, 8 VoIP Channels
The Matrix SETU VFX808 is an 8 FXS port VoIP gateway engineered to connect up to 8 analog telephones, fax machines, or PA systems into an IP-PBX network.
Product Overview
The Matrix SETU VFX808 provides 8 FXS extension ports to integrate analog desk telephones, cordless DECT phones, fax machines, and overhead paging systems into IP telecommunication networks. It preserves investments in existing analog wiring and terminal instruments while granting access to IP-PBX features. Equipped with enterprise voice DSPs, the SETU VFX808 features G.168 echo cancellation, configurable ring frequency and cadence, and high-fidelity T.38 fax transmission.
Why Buy This Product
8 Analog Extension Ports
Connects 8 analog telephone instruments or fax machines to IP-PBX systems.
High-Reliability T.38 Faxing
Ensures error-free fax transmission over IP networks using real-time T.38 relay.
MWI & Caller ID Support
Generates message waiting indicator signals and FSK/DTMF caller ID on analog phones.
Best for These Applications
Hotels & Lodging
Connecting room analog desk phones to a modern cloud or IP hotel PBX.
Multi-Tenant Residential
Linking apartment intercom phones with centralized IP gatekeeper systems.
Manufacturing Facilities
Deploying long-distance analog extension phones across factory floors.
Key Advantages
- Long Loop Line Support: Drives analog extension lines up to 3 km without voice signal degradation.
- G.168 Echo Cancellation: Removes line echo and side-tone for crystal clear voice calls.
- Mass Provisioning Console: Supports TFTP, HTTP, and HTTPS auto-provisioning for quick deployment.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 1.5 |
| Shipping Weight | 1.7 |
| Fxo Ports | 0 |
| Fxs Ports | 8 |
| Gsm Channels | 0 |
| Pri Ports | 0 |
| Voip Channels | 8 |
| Sim Card Slots | 0 |
| Sip Accounts | 8 |
| Voip Protocols | SIP v2 (RFC3261), SDP, RTP, RTCP |
| Audio Codecs | G.711a/u, G.729A, G.723.1, iLBC |
| Fax Support | T.38 Real-Time Fax Relay & Pass-Through |
| Dtmf Modes | In-Band, RFC2833, SIP INFO |
| Echo Cancellation | G.168 Line Echo Cancellation (128ms) |
| Ethernet Ports | 2 x 10/100 Mbps RJ45 Ethernet Ports |
| Network Protocols | IPv4, DHCP, PPPoE, VLAN 802.1Q, STUN |
| Security Protocols | TLS 1.2, SRTP, HTTPS, Digest Authentication |
| Call Routing Features | FXS-to-VoIP Outbound, VoIP-to-FXS Inbound, Flexible Dial Plans, Message Waiting Indicator (MWI) |
| Power Supply | 12V DC, 2A External Power Adapter |
| Power Consumption | 16W Maximum |
| Mounting Form Factor | Desktop / Wall-Mountable Chassis |
| Dimensions | 302 x 185 x 48 mm |
| Operating Temperature | 0°C to 45°C |
| Certifications | CE, FCC, TEC, RoHS |
