SETU VFX880, Telecom, Gateway, Matrix Comsec, 8 FXO, 8 VoIP Channels
The Matrix SETU VFX880 is a high-density 8 FXO port VoIP gateway engineered to connect 8 analog PSTN trunk lines directly into IP-PBX servers and cloud telephony networks.
Product Overview
The Matrix SETU VFX880 features 8 FXO analog trunk ports to bridge 8 Telco landline copper circuits directly into modern IP-PBX systems like Asterisk, FreePBX, 3CX, and Matrix ETERNITY. It converts incoming and outgoing PSTN analog calls into standard SIP VoIP streams. Equipped with G.168 line echo cancellation, auto-tuning line impedance, and intelligent disconnect tone detection, the SETU VFX880 ensures reliable trunk clearing and pristine voice quality across all 8 PSTN connections.
Why Buy This Product
8 Landline FXO Connectivity
Connects 8 PSTN landlines directly to IP-PBX servers and cloud platforms.
Pristine Voice Quality
G.168 echo cancellation and impedance matching eliminate line noise and echo.
Secure SIP Transport
TLS/SRTP protocol support secures VoIP signaling and voice channels.
Best for These Applications
Mid-Sized Offices
Companies retaining 8 local landlines for incoming customer calls while migrating to IP.
Inbound Service Centers
Support desks taking high volumes of landline calls on IP headsets.
Hosted PBX Integrations
Connecting cloud telephony systems to local physical PSTN trunks.
Key Advantages
- Busy Tone Disconnect:Instantly detects disconnect tones to prevent hung PSTN lines.
- Caller ID Forwarding:Passes FSK and DTMF caller details seamlessly to IP extensions.
- Simple Web Management:Web-based administrative tool for rapid configuration and diagnostics.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 1.5 |
| Shipping Weight | 1.7 |
| Fxo Ports | 8 |
| Fxs Ports | 0 |
| Gsm Channels | 0 |
| Pri Ports | 0 |
| Voip Channels | 8 |
| Sim Card Slots | 0 |
| Sip Accounts | 8 |
| Voip Protocols | SIP v2 (RFC3261), SDP, RTP, RTCP |
| Audio Codecs | G.711a/u, G.729A, G.723.1, iLBC |
| Fax Support | T.38 Fax Relay & Pass-Through |
| Dtmf Modes | In-Band, RFC2833, SIP INFO |
| Echo Cancellation | G.168 Line Echo Cancellation (128ms) |
| Ethernet Ports | 2 x 10/100 Mbps RJ45 Ethernet Ports |
| Network Protocols | IPv4, DHCP, PPPoE, VLAN 802.1Q, STUN |
| Security Protocols | TLS 1.2, SRTP, HTTPS, Digest Authentication |
| Call Routing Features | PSTN-to-SIP Inbound Routing, SIP-to-PSTN Outbound Routing, Caller ID Detection, LCR Digit Manipulation |
| Power Supply | 12V DC, 2A External Power Adapter |
| Power Consumption | 15W Maximum |
| Mounting Form Factor | Desktop / Wall-Mountable |
| Dimensions | 302 x 185 x 48 mm |
| Operating Temperature | 0°C to 45°C |
| Certifications | CE, FCC, TEC, RoHS |
| Stock | 10 |
