S4A EL-800DS Double Door 350KG Magnetic Lock with LED & Lock Sensor

Name: S4A EL-800DS Double Door 350KG Magnetic Lock with LED & Lock Sensor
Brand: S4A
SKU: EL-800DS
Price: 19140 KES
Availability: InStock

star star star star star

0.0 (0 reviews)

280KG x 2 double door electromagnetic lock, built-in LED, lock sensors, 12V/24VDC.

The S4A EL-800DS is a double-door electromagnetic lock delivering 350KG x 2 (800LBS x 2) holding force, equipped with built-in LED indicators and lock status sensors.

verified 350KG x 2 / 800LBS x 2 verified LED & Lock Sensor verified 12V/24VDC

KES 19,140.00 KES 22,500.00

local_offer Save KES 3,360 today

1 Year Manufacturer Warranty

Variants

EL-800DS 350KG x 2 / 800LBS x 2 · LED & Lock Sensor · 12V/24VDC EL-800D 350KG x 2 / 800LBS x 2 · LED Indicator · Double Doors EL-800DST 350KG x 2 / 800LBS x 2 · LED, Sensor & Timer Delay · 12V/24VDC

Product Overview

The S4A EL-800DS is a professional double door electromagnetic lock providing 350KG x 2 (800LBS x 2) holding force. It features built-in Red/Green LED status indicators and lock status feedback sensors. Ideal for heavy commercial double doors.

Technical Specifications

Parameter	Specification
Product Weight	5.4
Shipping Weight	5.9
Lock Type	double
Holding Force Kg	700
Holding Force Lbs	1600
Holding Force Text	350KG x 2 (800Lbs x 2)
Lock Dimensions	570Lx55Wx25H(mm)
Armature Dimensions	190Lx45Wx11H(mm)*2
Operating Voltage	DC12V (Adjustable DC24V)
Current Draw	12V/500mA x 2, 24V/250mA x 2
Signal Output	Lock status feedback x 2
Led Indicator	Yes
Door Status Sensor	Yes
Time Delay	None
Suitable For	Wooden door, Glass door, Metal door, Fireproof door
Bracket Compatibility	L-Bracket, U-Bracket, ZL-Bracket
Operating Temperature	-20°C ~ 55°C (-4°F ~ 131°F)
Surface Temperature	≤ 20°C
Suitable Humidity	0~90% (non-condensing)
Shell Material	Anodized aluminum
Magnetic Material	Zinc
Armature Material	Zinc
