In Stock
S4A: EM-1200T
S4A EM-1200T Embedded Door 500KG Magnetic Lock
star star star star star
0.0
(0 reviews)
500KG embedded (mortise) electromagnetic lock, flush mount, 12V/24VDC.
The S4A EM-1200T is a mortise-mount (embedded) electromagnetic lock offering 500KG (1000LBS) holding force. Designed for flush concealed installation on swing doors.
verified
500KG / 1000LBS
verified
Embedded / Mortise Mount
verified
12V/24VDC
KES 13,340.00
KES 16,000.00
local_offer
Save KES 2,660
today
KES 0
(KES 13,340 × 1)
local_offer
Total saved: KES 0
1 Year Manufacturer Warranty
Product Overview
The S4A EM-1200T is a flush-mount mortise electromagnetic lock designed for wood, glass, metal, and fireproof doors. It provides a holding force of 500KG (1000LBS), hiding inside the door frame or header for clean architectural lines.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 4.5 |
| Shipping Weight | 4.8 |
| Lock Type | other |
| Holding Force Kg | 500 |
| Holding Force Lbs | 1000 |
| Holding Force Text | 500KG (1000LBS) |
| Lock Dimensions | 258Lx65.8Wx38.8H(mm) |
| Armature Dimensions | 185Lx60Wx13H(mm) |
| Operating Voltage | DC12V or DC24V |
| Current Draw | 12V/420mA, 24V/210mA |
| Signal Output | None |
| Led Indicator | No |
| Door Status Sensor | No |
| Time Delay | None |
| Suitable For | Wooden door, Glass door, Metal door, Fireproof door |
| Bracket Compatibility | |
| Operating Temperature | -10°C ~ 55°C (14°F ~ 131°F) |
| Surface Temperature | ≤ 20°C |
| Suitable Humidity | 0~90% (non-condensing) |
| Shell Material | Anodized aluminum |
| Magnetic Material | Zinc |
| Armature Material | Zinc |
