SpeedFace-V3L Access Control Terminal & Reader
ZKTeco SpeedFace-V3L Ultra-Slim Terminal, 500 Face / 3K FP / 3K Card, 2.4" Touch LCD, IP65 mullion casing, TCP/IP & Wiegand.
The ZKTeco SpeedFace-V3L is an ultra-slim mullion-style Visible Light Facial Recognition terminal designed specifically for tight mounting spaces such as aluminum door frames and turnstile posts. Equipped with a 2.4-inch touchscreen, it delivers high-performance face and fingerprint authentication in a minimalist housing.
Product Overview
Engineered for cost-conscious businesses seeking facial recognition technology, the SpeedFace-V3L supports 500 face templates, 3,000 fingerprints, and 3,000 RFID cards. Its narrow 58.5mm width allows seamless installation where traditional wide access readers cannot fit, while its IP65 weatherproof casing protects against outdoor elements.
Why Buy This Product
Ultra-Slim Mullion Design
Fits narrow 58.5mm aluminum glass door mullions and compact turnstile pillars.
Affordable Facial Recognition
Delivers advanced visible light face biometrics at an accessible entry-level price point.
IP65 Weather Resistance
Sealed housing ensures long term exterior durability against rain and ambient humidity.
Best for These Applications
Glass Door Storefronts & Offices
Ideal for narrow door stiles where standard wide biometric readers cannot be physically mounted.
Small Business Entrance Doors
Perfect for SMBs needing touchless face recognition for up to 500 personnel.
Key Advantages
- Flexible Mounting Footprint:Eliminates the need for wide backplates or wall cutting on modern glass and aluminum architecture.
- Standalone Lock Relay:Directly activates magnetic locks or electric strikes without requiring an external controller.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Category Page Featured | Yes |
| Product Weight | 0.28 |
| Shipping Weight | 0.48 |
| User Capacity | 500 |
| Fingerprint Capacity | 3000 |
| Face Capacity | 500 |
| Card Capacity | 3000 |
| Log Capacity | 150000 |
| Verification Speed | < 0.35s |
| Authentication Modes | Visible Light Face, Fingerprint, Card, Password |
| Ip Rating | IP65 |
| Tamper Detection | Yes |
| Communication Interfaces | TCP/IP, Wiegand Output, RS485, USB Host |
| Display | 2.4" Touchscreen LCD |
| Camera | 1.3MP Binocular Camera |
| Operating System | Linux |
| Dimensions | 185mm x 58.5mm x 20mm |
| Power Requirements | DC 12V 1.5A |
| Operating Temp | -10°C to 45°C |
| Operating Humidity | 10% to 90% |
| Certifications | CE, FCC, RoHS |
| Biometric Algorithm | ZKLiveFace V5.8 / ZKFinger VX10.0 |
| Far | < 0.0001% |
| Frr | < 0.01% |
| Recognition Distance | 0.3m - 1.5m |
| Supported Software | ZKBio Access, ZKBio CVAccess, BioTime |
| Wiegand Interface | Wiegand Output |
| Door Relay Output | 1 Lock Relay, Exit Button & Door Sensor Interface |
| Sensor Type | Optical Fingerprint Sensor & Binocular Camera |
| Mounting Options | Mullion Surface Mount Bracket |
| Credential Types | Face, Fingerprint, 125kHz EM Card, PIN |
| Stock | 10 |
