SETU VTEP 2P, Telecom, Gateway, Matrix Comsec, 2 PRI E1/T1 Ports, 60 VoIP Channels
The Matrix SETU VTEP 2P is a dual-port ISDN PRI E1/T1 VoIP gateway designed to connect 2 digital T1/E1 trunk circuits (60 voice channels) directly into IP-PBX networks.
Product Overview
The Matrix SETU VTEP 2P is a 2-port ISDN PRI gateway engineered for high-density enterprise environments. It provides 60 digital voice channels across 2 E1 circuits (48 channels for T1), bridging legacy digital Telco trunks into modern IP-PBX systems. Equipped with dual Ethernet interfaces, G.168 echo cancellation, Q.SIG inter-PBX signaling, and DID number translation, the SETU VTEP 2P delivers seamless corporate voice interconnectivity.
Why Buy This Product
60-Channel Dual PRI Capacity
Supports 2 full E1 digital PRI lines for 60 concurrent uncompressed voice calls.
Q.SIG Inter-PBX Networking
Interconnects legacy traditional PBX systems with new IP-PBX clusters seamlessly.
Secure TLS/SRTP Protocol
Encrypts voice streams and signaling payloads against unauthorized tapping.
Best for These Applications
Large Enterprise Headquarters
Companies operating 2 E1 PRI lines requiring direct IP integration.
Inbound Contact Centers
Contact centers taking high volumes of simultaneous customer calls.
Multi-PBX Consolidation
Linking legacy ISDN PBXs with cloud IP-PBX platforms.
Key Advantages
- 60 Concurrent Call DSPs:Ensures zero call blocking or audio distortion during peak calling hours.
- Fractional E1 Trunking:Supports custom channel mapping for flexible Telco bandwidth purchasing.
- Dual Ethernet Interfaces:Provides network redundancy and dedicated LAN/WAN separation.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 2 |
| Shipping Weight | 2.3 |
| Fxo Ports | 0 |
| Fxs Ports | 0 |
| Gsm Channels | 0 |
| Pri Ports | 2 |
| Voip Channels | 60 |
| Sim Card Slots | 0 |
| Sip Accounts | 60 |
| Voip Protocols | SIP v2 (RFC3261), SDP, RTP, RTCP |
| Audio Codecs | G.711a/u, G.729A, G.723.1, iLBC |
| Fax Support | T.38 Real-Time Fax Relay & Pass-Through |
| Dtmf Modes | In-Band, RFC2833, SIP INFO |
| Echo Cancellation | G.168 Line Echo Cancellation (128ms) |
| Ethernet Ports | 2 x 10/100 Mbps RJ45 Ethernet Ports |
| Network Protocols | IPv4, DHCP, PPPoE, VLAN 802.1Q, STUN |
| Security Protocols | TLS 1.2, SRTP, HTTPS, Digest Authentication |
| Call Routing Features | Dual PRI Routing, DID/DDI Translation, Least Cost Routing, Fractional E1 Mapping |
| Power Supply | 12V DC, 3A External Power Adapter |
| Power Consumption | 20W Maximum |
| Mounting Form Factor | Desktop / 1U Rackmount Brackets |
| Dimensions | 302 x 185 x 48 mm |
| Operating Temperature | 0°C to 45°C |
| Certifications | CE, FCC, TEC, RoHS |
| Stock | 4 |
