SETU VTEP 4P, Telecom, Gateway, Matrix Comsec, 4 PRI E1/T1 Ports, 120 VoIP Channels
The Matrix SETU VTEP 4P is a flagship 4-port ISDN PRI E1/T1 VoIP gateway delivering 120 concurrent digital voice channels for enterprise data centers, contact centers, and service providers.
Product Overview
The Matrix SETU VTEP 4P represents the top-of-the-line 4-port digital PRI gateway in the SETU VTEP series. Supporting 4 E1 lines (120 voice channels) or 4 T1 lines (96 channels), it is engineered for tier-1 contact centers, enterprise headquarters, and telecom service providers. Driven by quad-core voice DSP processing, the SETU VTEP 4P provides 120 simultaneous uncompressed voice channels, G.168 echo cancellation, Q.SIG inter-PBX networking, DID translation, and military-grade TLS/SRTP security.
Why Buy This Product
Maximum 120-Channel PRI Density
Bridges 4 full E1 ISDN PRI lines (120 channels) with IP networks from one unit.
Tier-1 Contact Center Performance
Built-in quad DSPs guarantee 120 concurrent calls without audio latency or packet loss.
TLS/SRTP Enterprise Protection
Full voice stream and signaling encryption across corporate WAN links.
Best for These Applications
Enterprise Contact Centers
Contact centers handling 120 simultaneous calls across 4 E1 digital lines.
Multinational HQ Telephony
Connecting 4 Telco digital trunks to centralized IP softswitches.
ITSP SIP Trunk Operators
Interconnecting ISDN PRI networks with SIP cloud infrastructure.
Key Advantages
- 120 Simultaneous Call DSPs:Handles high call volumes during emergency or peak sales periods without dropouts.
- Direct Inward Dialing (DID):Directs incoming calls across 120 channels straight to internal IP extensions.
- Flexible BNC / RJ45 Connection:Supports both 120-ohm RJ45 and 75-ohm BNC digital cabling.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 2.4 |
| Shipping Weight | 2.7 |
| Fxo Ports | 0 |
| Fxs Ports | 0 |
| Gsm Channels | 0 |
| Pri Ports | 4 |
| Voip Channels | 120 |
| Sim Card Slots | 0 |
| Sip Accounts | 120 |
| Voip Protocols | SIP v2 (RFC3261), SDP, RTP, RTCP |
| Audio Codecs | G.711a/u, G.729A, G.723.1, iLBC |
| Fax Support | T.38 Real-Time Fax Relay & Pass-Through |
| Dtmf Modes | In-Band, RFC2833, SIP INFO |
| Echo Cancellation | G.168 Line Echo Cancellation (128ms) |
| Ethernet Ports | 2 x 10/100 Mbps RJ45 Ethernet Ports |
| Network Protocols | IPv4, DHCP, PPPoE, VLAN 802.1Q, STUN |
| Security Protocols | TLS 1.2, SRTP, HTTPS, Digest Authentication |
| Call Routing Features | Quad PRI Routing, DID/DDI Translation, Least Cost Routing, Fractional E1 Mapping |
| Power Supply | 12V DC, 3.5A External Power Adapter |
| Power Consumption | 28W Maximum |
| Mounting Form Factor | Desktop / 1U Rackmount Brackets |
| Dimensions | 302 x 185 x 48 mm |
| Operating Temperature | 0°C to 45°C |
| Certifications | CE, FCC, TEC, RoHS |
| Stock | 2 |
