SETU VTEP 3P, Telecom, Gateway, Matrix Comsec, 3 PRI E1/T1 Ports, 90 VoIP Channels
The Matrix SETU VTEP 3P is a 3-port ISDN PRI E1/T1 VoIP gateway delivering 90 concurrent digital voice channels to connect high-capacity T1/E1 trunks with IP-PBX systems.
Product Overview
The Matrix SETU VTEP 3P features 3 ISDN PRI E1/T1 ports, handling up to 90 concurrent digital voice calls (72 for T1). Built for large-scale enterprise communication nodes and contact centers, it bridges 3 digital E1 circuits directly into IP networks. Featuring advanced G.168 echo cancellation, DID direct inward dialing translation, and TLS/SRTP security, the SETU VTEP 3P ensures crystal-clear voice communication and high availability.
Why Buy This Product
90-Channel 3-PRI Density
Provides 90 simultaneous digital voice channels across 3 E1 ISDN PRI trunks.
High-Volume Call Processing
Built-in hardware DSPs ensure zero channel congestion during burst traffic.
Military-Grade TLS Encryption
Encrypts voice streams and SIP signaling against unauthorized interception.
Best for These Applications
Large Outbound/Inbound Contact Centers
BPOs processing 90 simultaneous caller lines.
Corporate Telecom Hubs
Enterprise centers interconnecting 3 digital PRI trunks with IP servers.
VoIP Service Providers
Converting legacy ISDN customer trunks to SIP trunks.
Key Advantages
- 90 Concurrent VoIP Channels:Handles 90 uncompressed high-definition voice calls simultaneously.
- Direct Inward Dialing (DID):Directs incoming calls on any of the 90 channels directly to specific IP extension numbers.
- Dual Physical Connectors:Supports RJ45 120-ohm and dual BNC 75-ohm coaxial connections.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 2.2 |
| Shipping Weight | 2.5 |
| Fxo Ports | 0 |
| Fxs Ports | 0 |
| Gsm Channels | 0 |
| Pri Ports | 3 |
| Voip Channels | 90 |
| Sim Card Slots | 0 |
| Sip Accounts | 90 |
| Voip Protocols | SIP v2 (RFC3261), SDP, RTP, RTCP |
| Audio Codecs | G.711a/u, G.729A, G.723.1, iLBC |
| Fax Support | T.38 Real-Time Fax Relay & Pass-Through |
| Dtmf Modes | In-Band, RFC2833, SIP INFO |
| Echo Cancellation | G.168 Line Echo Cancellation (128ms) |
| Ethernet Ports | 2 x 10/100 Mbps RJ45 Ethernet Ports |
| Network Protocols | IPv4, DHCP, PPPoE, VLAN 802.1Q, STUN |
| Security Protocols | TLS 1.2, SRTP, HTTPS, Digest Authentication |
| Call Routing Features | Triple PRI Routing, DID/DDI Translation, Least Cost Routing, Fractional E1 Mapping |
| Power Supply | 12V DC, 3A External Power Adapter |
| Power Consumption | 24W Maximum |
| Mounting Form Factor | Desktop / 1U Rackmount Brackets |
| Dimensions | 302 x 185 x 48 mm |
| Operating Temperature | 0°C to 45°C |
| Certifications | CE, FCC, TEC, RoHS |
| Stock | 2 |
