180KG single door electromagnetic lock, 12V/24VDC input, anodized aluminum casing.
The S4A EL-350 is a standard single door surface-mounted electromagnetic lock offering 180KG (350LBS) holding force. Perfect for office doors and light entry access.
verified180KG / 350LBSverified12V/24VDCverifiedSurface Mount
KES 5,568.00KES 6,500.00
local_offerSave KES 932 today
KES 0(KES 5,568 × 1)
local_offerTotal saved: KES 0
1 Year Manufacturer Warranty
Variants
EL-350180KG / 350LBS · 12V/24VDC · Surface MountEL-350ST180KG / 350LBS · LED & Lock Sensor · 12V/24VDC
Product Overview
The S4A EL-350 is a reliable single door surface mount magnetic lock. Delivering a holding force of 180KG (350LBS), it is ideal for wooden doors, glass doors, metal doors, and fireproof doors. It supports dual operating voltage configuration and is fail-safe.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 1.02 |
| Shipping Weight | 1.2 |
| Lock Type | single |
| Holding Force Kg | 180 |
| Holding Force Lbs | 350 |
| Holding Force Text | 180KG (350LBS) |
| Lock Dimensions | 170Lx41.5Wx20.5H(mm) |
| Armature Dimensions | 130Lx33Wx9.3H(mm) |
| Operating Voltage | DC12V (Option DC24V) |
| Current Draw | 12V/400mA, 24V/200mA |
| Signal Output | None |
| Led Indicator | No |
| Door Status Sensor | No |
| Time Delay | None |
| Suitable For | Wooden door, Glass door, Metal door, Fireproof door |
| Bracket Compatibility | L-Bracket, U-Bracket, ZL-Bracket |
| Operating Temperature | -20°C ~ 55°C (-4°F ~ 131°F) |
| Surface Temperature | ≤ 20°C |
| Suitable Humidity | 0~90% (non-condensing) |
| Shell Material | Anodized aluminum |
| Magnetic Material | Zinc |
| Armature Material | Zinc |
| Stock | 8 |
