S4A EL-600DS Double Door 280KG Magnetic Lock with LED & Lock Sensor

Name: S4A EL-600DS Double Door 280KG Magnetic Lock with LED & Lock Sensor
Brand: S4A
SKU: EL-600DS
Price: 14500 KES
Availability: InStock

star star star star star

0.0 (0 reviews)

280KG x 2 double door electromagnetic lock, built-in LED, lock sensors, 12V/24VDC.

The S4A EL-600DS is a double-door electromagnetic lock delivering 280KG x 2 (600LBS x 2) holding force, equipped with built-in LED indicators and lock status sensors.

verified 280KG x 2 / 600LBS x 2 verified LED & Lock Sensor verified 12V/24VDC

KES 14,500.00 KES 16,800.00

local_offer Save KES 2,300 today

1 Year Manufacturer Warranty

Variants

EL-600DS 280KG x 2 / 600LBS x 2 · LED & Lock Sensor · 12V/24VDC EL-600D 280KG x 2 / 600LBS x 2 · 12V/24VDC · Double Swing Doors EL-600DST 280KG x 2 / 600LBS x 2 · LED, Sensor & Timer Delay · 12V/24VDC

Product Overview

The S4A EL-600DS is a professional double door electromagnetic lock providing 280KG x 2 (600LBS x 2) holding force. It features a built-in LED status indicator and a lock status feedback sensor. Ideal for commercial double doors where monitoring is required.

Technical Specifications

Parameter	Specification
Product Weight	4
Shipping Weight	4.4
Lock Type	double
Holding Force Kg	560
Holding Force Lbs	1200
Holding Force Text	280KG x 2 (600Lbs x 2)
Lock Dimensions	500Lx48.5Wx25H(mm)
Armature Dimensions	180Lx38Wx11H(mm)*2
Operating Voltage	DC12V (Adjustable DC24V)
Current Draw	12V/500mA x 2, 24V/250mA x 2
Signal Output	Lock status feedback x 2
Led Indicator	Yes
Door Status Sensor	Yes
Time Delay	None
Suitable For	Wooden door, Glass door, Metal door, Fireproof door
Bracket Compatibility	L-Bracket, U-Bracket, ZL-Bracket
Operating Temperature	-10°C ~ 55°C (14°F ~ 131°F)
Surface Temperature	≤ 20°C
Suitable Humidity	0~90% (non-condensing)
Shell Material	Anodized aluminum
Magnetic Material	Zinc
Armature Material	Zinc
