SpeedFace-V5L Access Control Terminal & Reader
ZKTeco SpeedFace-V5L AI Facial Terminal, 10K Face/FP/Card capacity, 5.0" Touch LCD, 2MP WDR Binocular Camera, IP65 weather rating, TCP/IP, Wiegand & RS485.
The ZKTeco SpeedFace-V5L is a premium Linux-based Visible Light Facial Recognition terminal engineered with deep learning algorithms for ultra-fast, contactless authentication. Designed for demanding enterprise environments, it combines 2MP binocular WDR live face detection, optical fingerprint scanning, and RFID card verification to deliver uncompromised security.
Product Overview
Built for corporate headquarters, industrial complexes, and high-security government facilities, the ZKTeco SpeedFace-V5L redefines physical access control. Its visible light recognition engine operates flawlessly in zero-light conditions as well as bright sunlight, recognizing users in under 0.3 seconds. By integrating advanced anti-spoofing algorithms with multiple authentication modalities, the terminal effectively eliminates proxy clocking and unauthorized entry attempts.
Why Buy This Product
Touchless Hygiene & High Speed
Provides rapid touchless identity verification in under 0.3 seconds, preventing queues at busy entry points.
AI Deep Learning Protection
Advanced binocular camera system actively blocks biometric fraud attempts via photos, videos, or silicon masks.
IP65 Weatherproof Chassis
Fully sealed IP65 casing ensures continuous operational reliability across outdoor perimeter gates and dusty environments.
Best for These Applications
Corporate Lobbies & Tech Hubs
Ideal for turnstiles and main entry gates requiring fast throughput and modern touchless aesthetics.
Industrial & Manufacturing Sites
Perfect for factory entry points where workers need reliable multi-factor access control.
Key Advantages
- Wide Dynamic Range Camera:2MP WDR binocular camera compensates for backlighting and extreme contrast to verify faces in bright sunlight or total darkness.
- Comprehensive Door Linkage:Directly controls magnetic locks, electric strikes, warning buzzers, and exit buttons without requiring separate relay boards.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Category Page Featured | Yes |
| Product Weight | 0.45 |
| Shipping Weight | 0.7 |
| User Capacity | 10000 |
| Fingerprint Capacity | 10000 |
| Face Capacity | 10000 |
| Card Capacity | 10000 |
| Log Capacity | 200000 |
| Verification Speed | < 0.3s |
| Authentication Modes | Visible Light Face, Fingerprint, Card, Password |
| Ip Rating | IP65 |
| Tamper Detection | Yes |
| Communication Interfaces | TCP/IP, Wiegand Input/Output, RS485, USB Host |
| Display | 5.0" Touchscreen LCD |
| Camera | 2MP Binocular WDR Camera |
| Operating System | Linux |
| Dimensions | 203mm x 91.93mm x 22.5mm |
| Power Requirements | DC 12V 3A |
| Operating Temp | -10°C to 45°C |
| Operating Humidity | 10% to 90% |
| Certifications | CE, FCC, RoHS |
| Biometric Algorithm | ZKLiveFace V5.8 / ZKFinger VX10.0 |
| Far | < 0.0001% |
| Frr | < 0.01% |
| Recognition Distance | 0.3m - 2.0m |
| Supported Software | ZKBio Access, ZKBio CVAccess, ZKBioSecurity |
| Wiegand Interface | Wiegand Input & Output |
| Door Relay Output | 1 Lock Relay, Alarm Relay, Exit Button & Door Sensor |
| Sensor Type | Optical Fingerprint Sensor & Dual WDR Camera |
| Mounting Options | Wall Mount / Turnstile Mount Bracket |
| Credential Types | Face, Fingerprint, 125kHz EM Card, PIN |
| Stock | 1 |
