SETU VFXTH0024, Telecom, Gateway, Matrix Comsec, 24 FXS, 24 VoIP Channels, 1U Rackmount
The Matrix SETU VFXTH0024 is a high-density 24 FXS 1U rackmount VoIP gateway engineered to connect 24 analog telephones, faxes, or PA systems into IP-PBX environments.
Product Overview
The Matrix SETU VFXTH0024 offers 24 FXS extension ports in a robust 1U 19-inch rackmount chassis. Designed for high-density hospitality, enterprise, and residential deployments, it connects 24 analog phones directly to IP-PBX platforms like Asterisk, 3CX, and Matrix ETERNITY. With hardware DSP voice processing, the SETU VFXTH0024 provides 24 simultaneous voice channels, G.168 echo cancellation, T.38 fax support, and secure Web GUI configuration.
Why Buy This Product
24 High-Density FXS Ports
Connects 24 analog phones to IP networks from a single compact 1U rack space.
Hospitality PBX Partner
Connects 24 guest room desk phones directly to modern cloud hotel PBXs.
Military-Grade TLS Encryption
Secures voice streams and SIP signals from interception across public IP links.
Best for These Applications
Medium-Sized Hotels
Connecting room extension lines to central IP telephony platforms.
Corporate HQ Deployments
Integrating large blocks of legacy analog desk phones with new IP-PBXs.
Educational Campuses
Connecting classroom analog phones across campus buildings.
Key Advantages
- Amphenol / RJ11 Connectivity:High-density Telco connector options for clean punch-down block wiring.
- Long Loop Line Performance:Drives analog extension lines up to 3 km without audio attenuation.
- Dual Gigabit Networking:High-speed Gigabit Ethernet interfaces with VLAN voice isolation.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 3.4 |
| Shipping Weight | 3.9 |
| Fxo Ports | 0 |
| Fxs Ports | 24 |
| Gsm Channels | 0 |
| Pri Ports | 0 |
| Voip Channels | 24 |
| Sim Card Slots | 0 |
| Sip Accounts | 24 |
| Voip Protocols | SIP v2 (RFC3261), SDP, RTP, RTCP |
| Audio Codecs | G.711a/u, G.729A, G.723.1, iLBC |
| Fax Support | T.38 Real-Time Fax Relay & Pass-Through |
| Dtmf Modes | In-Band, RFC2833, SIP INFO |
| Echo Cancellation | G.168 Line Echo Cancellation (128ms) |
| Ethernet Ports | 2 x 10/100/1000 Mbps RJ45 Gigabit Ethernet Ports |
| Network Protocols | IPv4, DHCP, PPPoE, VLAN 802.1Q, STUN |
| Security Protocols | TLS 1.2, SRTP, HTTPS, Digest Authentication |
| Call Routing Features | FXS-to-SIP Outbound, SIP-to-FXS Inbound, Flexible Extension Dialing, MWI Signaling |
| Power Supply | 100-240V AC (50/60Hz) Internal Power Supply |
| Power Consumption | 32W Maximum |
| Mounting Form Factor | 1U 19-inch Rackmount Chassis |
| Dimensions | 440 x 240 x 44 mm |
| Operating Temperature | 0°C to 45°C |
| Certifications | CE, FCC, TEC, RoHS |
| Stock | 6 |
