In Stock
S4A: EL-600ST
S4A EL-600ST Single Door 280KG Magnetic Lock with LED & Time Delay
star star star star star
0.0
(0 reviews)
280KG magnetic lock with LED status light, lock sensor, and adjustable time delay.
The S4A EL-600ST is a 280KG (600LBS) single door electromagnetic lock featuring a built-in time delay function, LED status light, and lock sensor.
verified
280KG / 600LBS
verified
LED, Sensor & Time Delay
verified
12V/24VDC
KES 8,120.00
KES 9,500.00
local_offer
Save KES 1,380
today
KES 0
(KES 8,120 × 1)
local_offer
Total saved: KES 0
1 Year Manufacturer Warranty
Variants
EL-600ST 280KG / 600LBS · LED, Sensor & Time Delay · 12V/24VDC EL-600 280KG / 600LBS · 12V/24VDC · Swing Door EL-600SD 280KG / 600LBS · LED & Lock Sensor · 12V/24VDC EL-600SZ 280KG / 600LBS · LED, Sensor & Buzzer · 12V/24VDC EL-600SA 280KG / 600LBS · Built-in Access Control · 9-Wire / 12V/24VDC
Product Overview
The S4A EL-600ST single door electromagnetic lock features an adjustable time delay function, allowing users to define the unlock duration before the system automatically locks again. It also features a dual Red/Green LED indicator and lock sensor.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 2 |
| Shipping Weight | 2.2 |
| Lock Type | single |
| Holding Force Kg | 280 |
| Holding Force Lbs | 600 |
| Holding Force Text | 280KG (600LBS) |
| Lock Dimensions | 250Lx48.5Wx25H(mm) |
| Armature Dimensions | 180Lx38Wx11H(mm) |
| Operating Voltage | 12V/24VDC |
| Current Draw | 12V/500mA, 24V/250mA |
| Signal Output | Lock status feedback |
| Led Indicator | Yes |
| Door Status Sensor | No |
| Time Delay | Yes (Adjustable) |
| Suitable For | Wooden door, Glass door, Metal door, Fireproof door |
| Bracket Compatibility | L-Bracket, U-Bracket, ZL-Bracket |
| Operating Temperature | -20°C ~ 55°C (-4°F ~ 131°F) |
| Surface Temperature | ≤ 20°C |
| Suitable Humidity | 0~90% (non-condensing) |
| Shell Material | Anodized aluminum |
| Magnetic Material | Zinc |
| Armature Material | Zinc |
