Matrix 64 Channel Extreme Series NVR with 8 SATA Ports
64 IP Channels | 8 SATA Bays (144TB Max) | RAID 0/1/5/10 | 512Mbps Throughput | Hot-Swappable
Massive storage 64-channel NVR (SATATYA PARAM NVR6408X) featuring 8 SATA HDD bays (144TB max storage capacity), hot-swappable drive trays, hardware RAID 0/1/5/10 protection, and 512 Mbps throughput.
Product Overview
Built for large-scale enterprise installations requiring massive local storage retention, the SATATYA PARAM NVR6408X houses 8 SATA HDD bays providing up to 144TB raw capacity. Featuring hot-swappable drive drawers, hardware RAID 5/10 rebuilds, dual 4K HDMI, and 512 Mbps throughput, it safeguards high-density surveillance operations.
Why Buy This Product
144TB Massive Storage
Eight SATA HDD bays provide long-term video archive retention for regulatory compliance.
Hardware RAID Protection
Dedicated hardware RAID controller ensures high throughput writing and disk recovery without CPU overhead.
Best for These Applications
Central Banks & Data Centers
Meets mandatory 90 to 180-day video archive compliance requirements.
Seaports & Freight Hubs
Monitors extensive container yards, perimeter walls, and heavy vehicle traffic.
Key Advantages
- 16 Alarm Inputs / 8 Outputs:Extensive physical I/O interface for connecting perimeter intrusion sensors, strobe lights, and door contacts.
- 2U Heavy-Duty Chassis:Industrial-grade server chassis designed for 24/7 continuous operation in standard server racks.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 8.5 |
| Shipping Weight | 10.2 |
| Channels | 64 |
| Poe Ports | 0 |
| Hdd Bays | 8 |
| Max Storage T B | 144 |
| Max Storage Per Bay T B | 18 |
| Decoding Capability | 4K UHD (3840 x 2160) |
| Throughput Mbps | 512 |
| Incoming Bandwidth Mbps | 512 |
| Outgoing Bandwidth Mbps | 512 |
| Series | PARAM |
| Max Camera Resolution M P | 12 |
| Video Compression | H.265, H.264, Motion JPEG |
| Audio Compression | G.711u, G.711a, AAC |
| Video Outputs | 2x HDMI (4K Concurrent), 1x VGA (1080p) |
| Network Interfaces | 2x Gigabit RJ-45 Ethernet Ports (10/100/1000 Mbps) |
| Raid Support | RAID 0, RAID 1, RAID 5, RAID 10 |
| Usb Ports | 1x USB 3.0, 2x USB 2.0 |
| Alarm Input Output | 16 Inputs / 8 Outputs |
| Audio Input Output | 1x RCA Input / 1x RCA Output |
| Vms Integration | Matrix SATATYA SAMAS Native VMS & ONVIF Profile S/G/T |
| Cascading Support | Up to 20 NVRs without server |
| Smart Analytics | Motion Detection, Tripwire, Intrusion Detection, Object Left/Removed, Face Recognition Trigger |
| Power Source | 100-240VAC Internal Power Supply |
| Power Consumption Watts | 55W (Without HDD) |
| Rack Mountable | Yes |
| Form Factor | 2U Standard Rackmount |
| Dimensions | 440 x 430 x 88 mm |
| Operating Temperature | 0°C to +50°C |
| Stock | 4 |
