Matrix 8 Channel Extreme Series NVR with 1 SATA Port
8 IP Channels | 1 SATA Bay (18TB Max) | H.265 Compression | 180Mbps Throughput | 4K UHD HDMI
Compact 8-channel rackmount NVR (SATATYA PARAM NVR0801X) delivering 180 Mbps decoding throughput, 4K UHD HDMI video output, H.265 video compression, and support for up to 18TB storage across 1 SATA HDD bay.
Product Overview
Engineered specifically for small-to-medium business security deployments, the SATATYA PARAM NVR0801X provides 8-channel IP camera streaming with up to 180 Mbps throughput. With native 4K HDMI video output, H.265 compression efficiency, and built-in event analytics, it secures small office branches, retail stores, and commercial premises with uncompromised clarity.
Why Buy This Product
50% Bandwidth Optimization
H.265 smart encoding drastically cuts storage requirements while preserving 4K image sharpness.
Direct 4K UHD Output
Monitor live camera feeds directly on 4K displays without requiring dedicated workstation graphics cards.
Serverless Cascading
Link and view up to 20 NVR units simultaneously from a single master NVR interface without buying additional VMS software.
Best for These Applications
Retail Outlets & Showrooms
Ideal for monitoring cash registers, customer aisles, and inventory rooms with high-resolution 4K detail.
Branch Offices & Clinics
Provides self-contained local recording with remote viewing over web and mobile apps for central management.
Key Advantages
- High Throughput Processing:180 Mbps bus bandwidth allows all 8 channels to record at full frame rate at up to 4K resolution simultaneously.
- Broad ONVIF Compatibility:Seamlessly connect third-party IP cameras using ONVIF Profile S, G, and T open standard protocols.
Frequently Asked Questions
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Weight | 3.5 |
| Shipping Weight | 4.5 |
| Category Page Featured | Yes |
| Channels | 8 |
| Poe Ports | 0 |
| Hdd Bays | 1 |
| Max Storage T B | 18 |
| Max Storage Per Bay T B | 18 |
| Decoding Capability | 4K UHD (3840 x 2160) |
| Throughput Mbps | 180 |
| Incoming Bandwidth Mbps | 180 |
| Outgoing Bandwidth Mbps | 180 |
| Series | PARAM |
| Max Camera Resolution M P | 8 |
| Video Compression | H.265, H.264, Motion JPEG |
| Audio Compression | G.711u, G.711a, AAC |
| Video Outputs | 1x HDMI (4K 3840x2160), 1x VGA (1080p) |
| Network Interfaces | 1x Gigabit RJ-45 Ethernet Port (10/100/1000 Mbps) |
| Usb Ports | 1x USB 3.0, 1x USB 2.0 |
| Alarm Input Output | 2 Inputs / 1 Output |
| Audio Input Output | 1x RCA Input / 1x RCA Output |
| Vms Integration | Matrix SATATYA SAMAS Native VMS & ONVIF Profile S/G/T |
| Cascading Support | Up to 20 NVRs without server |
| Smart Analytics | Motion Detection, Tripwire, Intrusion Detection, Camera Tamper |
| Power Source | 12VDC, 3A Power Adapter |
| Power Consumption Watts | 15W (Without HDD) |
| Rack Mountable | Yes |
| Form Factor | 1U Compact Desktop/Rackmount |
| Dimensions | 300 x 220 x 44 mm |
| Operating Temperature | 0°C to +50°C |
| Stock | 5 |
